Install using Helm

On this page

In this tutorial you will learn how to use a Helm package provided by Curity to install the Curity Identity Server on a Kubernetes Cluster.

When installing this chart the release creates the following resources for a runtime node in the Kubernetes cluster:

  • A Deployment
  • A Service

New to Kubernetes and Helm?

If you are new to Kubernetes platform take a look at the Concepts behind Kubernetes. If you are not familiar with Helm - the Kubernetes package manager, have a look at the Helm documentation.


What you need to follow this tutorial:

Installing the Helm Chart

In this quickstart you will perform the following steps:

  • add and update a new chart repository
  • install the curity/idsvr chart
    • with the latest release of the Curity Identity Server and
    • your own admin password.

When installing the Helm chart for the very first time add Curity to the list of chart repositories:

$ helm repo add curity https://curityio.github.io/idsvr-helm/

Make sure the repository is up to date before installing the chart:

$ helm repo update

Install the chart. You have to provide a password. With the following command you also specify to use the latest Docker image and that you want to enable the admin UI:

$ helm install idsvr-tutorial curity/idsvr \
--set image.tag=latest \
--set curity.config.password=Pass1 \
--set curity.config.uiEnabled=true

Give it some time to finish setting up the cluster. You can check the status of the pods using Kubernetes command kubectl:

$ kubectl get pods --namespace default --selector="app.kubernetes.io/instance=idsvr-tutorial"

The result will look similar to the example below. Note the list of pods that are not ready yet and observe their status.

idsvr-tutorial-admin-96cdb5bd6-fnb4b 0/1 Running 0 5s
idsvr-tutorial-runtime-7c69bf6dc6-xkfzh 0/1 Running 0 5s

You need to configure port forwarding for your pod to be able to access the Admin UI. To do that you need the name of the admin pod. You can copy the name from the output of the get pods command, or you can use the following command which will find the name for you and put it in an environment variable. You can also find this command in the output of the helm install command:

$ export POD_NAME=$(kubectl get pods --namespace default -l "role=idsvr-tutorial-admin,app.kubernetes.io/instance=idsvr-tutorial" -o jsonpath="{.items[0].metadata.name}")
$ kubectl port-forward $POD_NAME 6749:6749

Once the server is up, you can access the Admin UI by visiting https://localhost:6749/admin.

Next Steps

Now the Curity Identity Server is up and running but without any configuration. The next step is to set up the basic profiles and services. Move on to the First Configuration Tutorial.

Uninstalling the Chart

You can uninstall and delete the resources created by this tutorial with the following command:

$ helm delete idsvr-tutorial

A more advanced example

If you want to learn more about deploying the Curity Identity Server with Helm, continue with Encrypted Configuration using Helm.

The Helm chart and its related documentation as well as the source code can be found on GitHub.
